• Push-buttons for breaker operations
• Status texts
Alternatively, you can use TDU 107.
2.1.6 M-Logic
• Simple logic configuration tool
• Selectable input events
• Selectable output commands
2.2 AC configuration
The AGC is designed to measure voltages between 100 and 690 V AC. The AC wiring diagrams are shown in the Installation
Instructions. You can select the AC configuration in menu 9130 (three-phase, single phase and split phase).
Change the settings using the display or the USW. To use the display, press the JUMP push-button and go to menu 9130. The
display looks like this:
Automatic Gen-set Controller
multi-line AGC
3 phase L1L2L3
RESET SAVE
G 0 0 0V
9130 AC config.
Use the or push-button to select the AC configuration. Press the push-button until SAVE is underscored, and then
press to save the new setting.
DANGER!
Configure the correct AC configuration. If in doubt, contact the switchboard manufacturer for information.
2.2.1 Three-phase system
When the AGC is delivered from the factory, the three-phase system is selected. When this configuration is used, all three phases
must be connected to the AGC.
The table below contains the parameters to make the system ready for three-phase measuring.
The example below is with 230/400 V AC, which can be connected directly to the AGC's terminals without the use of a voltage
transformer. If a voltage transformer is necessary, the nominal values of the transformer should be used instead.
Setting
Adjustment Description
Adjust to
value
6004 G nom. voltage Phase-phase voltage of the generator 400 V AC
6041 G transformer Primary voltage of the G voltage transformer (if installed) 400 V AC
6042 G transformer Secondary voltage of the G voltage transformer (if installed) 400 V AC
6051 BB transformer set 1 Primary voltage of the BB voltage transformer (if installed) 400 V AC
6052 BB transformer set 1 Secondary voltage of the BB voltage transformer (if installed) 400 V AC
6053 BB nom. voltage set 1 Phase-phase voltage of the busbar 400 V AC
DESIGNER'S HANDBOOK 4189341275A EN Page 12 of 196
