Page #167 background imageLoading...
Page #167 background image
INFO
The standard genset controller has a limited number of digital inputs. To have all the required the digital inputs, the
controller may need additional hardware options.
6.41.1 External analogue set point terminals
Terminal Function Technical data Description
40 -10/+10 V DC Analogue input f/P set point
41 Com. Common Common
42 -10/+10 V DC Analogue input U/Q set point
6.41.2 Other sources of external analogue set points
The AGC does not require hardware option M12 (and digital inputs for set point activation) if it uses these other sources of external
analogue set points.
External analogue set points using Modbus
The external analogue set points can be sent over Modbus.
More information
See Option H2 and H9 Modbus communication and the AGC Modbus tables for more information.
External analogue set points using CIOs
External analogue set points can come from a CIO. Use M-Logic to activate the set point(s).
More information
See CIO 308 Installation and commissioning guide and Option A10 for more information.
RRCR external set point control
The grid can use a Radio Ripple Control Receiver (RRCR) for load management.
More information
See Additional Functions, RRCR external set point control in the Designer's Handbook for more information.
6.42 Outputs
The controller has a number of output functions which can be configured to any available relay.
Output function
Auto Semi Test Man Block Configurable Output type
Trip NEL 1 X X X X X Configurable Pulse
Trip NEL 2 X X X X X Configurable Pulse
Trip NEL 3 X X X X X Configurable Pulse
6.42.1 Function description
Trip NEL 1: This output is used to trip load groups.
Trip NEL 2: This output is used to trip load groups.
Trip NEL 3: This output is used to trip load groups.
DESIGNER'S HANDBOOK 4189341275A EN Page 167 of 196
