Deif AGC-4 Mk II Designers Handbook

Term Abbreviation Explanation
Current transformer CT
Display unit DU-2
Genset G
Genset breaker GB
Governor GOV
Load take over LTO
Mains breaker MB
Mains power export MPE
Menu (XXXX) A group of parameters.
M-Logic The PLC-type tool accessible from the utility software.
Multi-line-2 ML-2 A DEIF platform, which includes the AGC-4 Mk II.
Nominal power P nom
Nominal reactive power Q nom
Nominal voltage U nom
Parameter (XXXX)
A configurable setting (sometimes also called Channel in the PC utility
software).
PC utility software USW
Resistance measurement input RMI
Software SW
Touch display unit TDU 107
Voltage transformer VT
1.2 Warnings, legal information and safety
1.2.1 Warnings and notes
Throughout this document, a number of warnings and notes with helpful user information will be presented. To ensure that these are
noticed, they will be highlighted as follows in order to separate them from the general text.
Warnings
DANGER!
This highlights dangerous situations. If the guidelines are not followed, these situations could result in death, serious
personal injury, and equipment damage or destruction.
CAUTION
This highlights potentially dangerous situations. If the guidelines are not followed, these situations could result in personal
injury or damaged equipment.
Notes
INFO
Notes provide general information, which will be helpful for the reader to bear in mind.
