Timers
Time In Out Misc
G 400 400 400V
9120 Service menu
Available selections
Time
Shows the alarm timer and the remaining time. The indicated remaining time is minimum remaining time. The timer will count
downwards when the set point has been exceeded.
Automatic Gen-set Controller
multi-line AGC
Remaining time 10.0s
Up Down
G 400 400 400V
1000 -P>
IN (digital input)
Shows the status of the digital inputs.
Automatic Gen-set Controller
multi-line AGC
Input = 0
Up Down
G 400 400 400V
Digital input 54
OUT (digital output)
Shows the status of the digital outputs.
Automatic Gen-set Controller
multi-line AGC
Output A 0
Up Down
G 400 400 400V
Relay 5
MISC (miscellaneous)
Shows miscellaneous messages.
Automatic Gen-set Controller
multi-line AGC
Various = 0
Up Down
G 400 400 400V
M-Logic enabled
6.12 Service timers
The controller can monitor the maintenance intervals. Four service timers are available to cover different intervals. The service
timers are set up in menus 6110, 6120, 6300 and 6310.
