Pag 52 / 154
Manuale Lyra 600 sx elettr eng
Fig. 4.1.3A
Fig. 4.1.3B
NOTE The infeed conveyor must be lifting in two time: it is necessary to
disassembly the infeed conveyor in two parts (fig. 4.1.4).
NOTE To lift the infeed conveyor using the same procedure adopted for the
machine, using forklift (fig. 4.1.4).
Fig. 4.1.4 Lifting of the infeed conveyor
