Steps
1. Slide and insert the M.2 solid-state drive carrier into the M.2 solid-state drive module.
2. Push the carrier handle to secure the M.2 solid-state drive carrier in place.
Next steps
1. Follow the procedure in After working inside your computer.
Slim optical-drive
Removing the slim optical-drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the right-side cover.
About this task
The following images provide a visual representation of the slim optical-drive removal procedure.
Removing and installing components
59
