Delta AS Series User Manual

Electrical specifications for the outputs
Model
Item
AS02PU-A AS04PU-A
Number of outputs
Four (2-axis) Eight (4-axis)
Connector type
Removable terminal blocks
Output form
differential output
Transistor-T (sinking) (NPN)
Output voltage
5 VDC*
1
5-30 VDC, 0.1A
Leakage current
< 10 uA
Minimum load
1 mA / 5 VDC
Maximum
load
Resistance
10 mA
0.1A
Inductance
N/A
Bulb
N/A
Maximum
output
frequency
Resistance
200 kHz 100 kHz
Maximum
Response
time
OFF→ON
0.1 μs 1.5 μs
ON→OFF
0.1 μs 1.5 μs
Output isolation
500 VAC
Weight
120 g
Note *1: Acutal output 4 VDC (high input impedance) to 3.3 VDC (10 mA)/point
