Delta AS Series User Manual

*3. If noise in the input voltage results in noise interference in the wiring, connect the module to a capacitor with
a capacitance between 0.1–0.47 μF with a working voltage of 25 V.
*4. Connect FE of the shielded cable to ground.
*5. Connect the terminal to ground.
*6. Every channel can work with the wiring shown above.
4.9.2 Wiring AS08AD-B
-10 V~+10V
V 1+
V1-
CHX
*2
1M
A G
1M
0V
24V
24 VDC
DC/DC
Con ve rter
+15V
-1 5V
AG
FE
*3
* 4
+
-
+24V
0V
-10 V~+10V
+24V
+
-
* 3
FE
0V
*5
V 2+
V2-
CHX
1M
AG
1M
*5
Shield ed c abl e *1
Shield ed c abl e *1
4-wir e: voltage input
3-wire: voltage input
*1. Use shielded cables to isolate the analog input signal cable from other power cables.
*2. If noise in the input voltage results in noise interference in the wiring, connect the module to a capacitor with
a capacitance between 0.1–0.47 μF with a working voltage of 25 V.
*3. Connect FE of the shielded cable to ground.
*4. Connect the terminal to ground.
*5. Every channel can work with the wiring shown above.
