Delta AS Series User Manual

 AS-FFTP01
88
42
61.5
25.2
AS -F FTP 0 1
NS
MS
AS -F FTP 0 1
NS
MS
1 TX+ 2 TX- 3 RX+ 4 N/C
5 N/C 6 RX- 7 N/C 8 N/C
4.14.2 Wiring the Communicational Function Cards
 AS-F232 wiring example:
DB9 male to DB9 female (standard cable)
AS-F232
(DB9 female)
+ +
Superior
machine
 AS-F422 wiring example:
3
4
1
2
6
7
8
9
CO
M
2/DB-9
AS-F422
Delta HMI seriesDOPA
2
1
3
4
T+
T-
R+
R-
Rx+
Rx-
Tx+
Tx-
RTS-
RTS+
CTS+
CTS-
 AS-F485 wiring example:
D+
D-
SG
D+ D- SG SG D+ D-
Master node
Slave node Slave node
Shielded
cable
Shielded
cable
Terminal
resistor
(120 ohm)
Terminal
resistor
(120 ohm)
