Delta AS Series User Manual

2.3 Digital Input/Output Module Specifications
2.3.1 General Specifications
 Electrical specifications for the inputs on digital input/output modules
(The signals passing through the inputs are 24 VDC signals.)
Module name
08AM10N
-A
16AM10N
-A
32AM10N
-A
64AM10N
-A
16AP11R
A
16AP11T
-A
16AP11P
-A
Number of inputs
8
16
32
64
8
8
8
Connector type
Removable terminal
block
MIL connector Removable terminal block
Input type
Digital input
Input form
Direct current (sinking or sourcing)
Input voltage/ current
24 VDC，5 mA
24 VDC
3.2 mA
24 VDC，5 mA
Input impedance
4.7 k Ω 7.5k Ω 4.7 k Ω
Action level
OFF→ON
>15 VDC
ON→OFF
<5 VDC
Response
time
OFF→ON
< 20 us
ON→OFF
< 200 us
Software filter time
Setting range: 0 ~ 25 ms; default: 10 ms
Maximum input
frequency
Varies according to the filter time; for example when the filter is 1 ms, the
maximum input frequency is 500 Hz, when 2 ms, 250 Hz.
Note: CPU scan time also affects the maximum input frequency.
Input signal
Voltage input
Sinking: The inputs are NPN transistors whose collectors are open
collectors.
Sourcing: The inputs are PNP transistors whose collectors are open
collectors.
Input isolation
500 VAC
Input display
When the optocoupler is driven, the input LED indicator is ON.
Weight
100 g
117 g
100 g
140 g
138 g
120 g
120 g
