2.12 Power Supply Module Adapter Specification
For easier wiring, this adaptor allows wiring on the bottom of the module instead of on the left-side of the
module. If you already purchased AS-PS02 or AS-PS02A, you do not need this adaptor to have an easier
wiring.
Unit: mm
88
104
18
26
75
