Delta AS Series - Error Codes and LED Indicators for High Speed Counter Module AS02 HC; Error Codes and LED Indicators for Load Cell Module AS02 LC; As02 Hc

12.4.4 Error Codes and LED Indicators for High Speed Counter Module
AS02HC
Error code Description
ERROR LED indicator status
ON Blinking
16#1605
Counted result in the latched area is not retainable (major
error)
V
16#1606
Module settings in the latced area is not retainable. (major
error)
V
16#1607
Module setting error
(major error)
V
16#1800
Counter overflow / underflow on CH1
V
16#1801
Counter overflow / underflow on CH2
V
16#1802
Linear count exceeding the set upper/lower limit on CH1
V
16#1803
Linear count exceeding the set upper/lower limit on CH2
V
16#1804
The variation in relation to a SSI encoder position
exceeding the limit on CH1
V
16#1805
The variation in relation to a SSI encoder position
exceeding the limit on CH2
V
16#1806
Abnormal SSI communication on CH1
V
16#1807
Abnormal SSI communication on CH2
V
16#1808
SSI absolute position cross zero point on CH1
V
16#1809
SSI absolute position cross zero point on CH2
V
12.4.5 Error Codes and LED Indicators for Load Cell Module AS02LC
Error code Description
ERROR LED indicator
A

D ERROR
16#1605
Hardware failure (the diver board included)
OFF
ON
16#1607
The external voltage is abnormal.
OFF
ON
16#1801*1
The external voltage is abnormal.
OFF
Blinking
16#1802*1 Hardware failure OFF Blinking
16#1807*1 Diver board failure OFF Blinking
16#1808
The signal received by channel 1 exceeds the range of
analog inputs or the SEN voltage is abnormal.
RUN: Blinking
STOP: OFF
Blinking
16#1809
The signal received by channel 1 exceeds the weight limit.
16#180A
The factory calibration in channel 1 is incorrect.
16#180B
The signal received by channel 2 exceeds the range of
analog inputs or the SEN voltage is abnormal.
16#180C
The signal received by channel 2 exceeds the weight limit.
16#180D
The factory calibration in channel 2 is incorrect.
