Delta AS Series User Manual

4.8.2 Wiring Digital Output Terminals
4.8.2.1 Output Circuits
There are three types of output units. They are relay outputs, transistor outputs, and differential outputs.
1. Relay output
250VAC
2A
I/O Relay
Y0.0
C0
I/O Relay
Y0.0
C0
30VDC
2A
2. Transistor output
5~3 0VDC
0.5A
C0
Y0.
0
+
I/O( )Sink
Y0.0
C0
+
5~3 0VDC
0.5A
I/O(Sou rce )
3. Differential output
FP
Y0.3+
Y0.3-
100k
2k
ASDA-A2
Shielded c able *1
HSIGN 4 6
/HS IGN
40
2k
FP
Y 0.0+
Y0.0 -
ASDA-A2
Shielded c able *1
SIGN 36
/SIGN 37
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
