Delta AS Series - Page 173

 Wiring the External Terminal Module UB-10-ID16A
Input form
Direct current (sinking or sourcing)
Input current/voltage
24 VDC. 5 mA
Output form
Transistor-P (souring)
Output
current/voltage
5 to 30 VDC. 0.1A
TB1
TB2
Length
UC-ET010-24D(1M)(28AWG)
UC-ET020-24D(2M)
UC-ET030-24D(3M)
(28AWG)
(28AWG)
Length:
39 40
1 2
500+10mm
-
19 20
1 2
19 20
1
2
#1
#2
#1
TB1 Y0.0 Y0.2 Y0.4 Y0.6 Y0.8 Y0.10 Y0.12 Y0.14 - C0
TB2 Y0.1 Y0.3 Y0.5 Y0.7 Y0.9 Y0.11 Y0.13 Y0.15 - C0
#2
TB1 X0.0 X0.2 X0.4 X0.6 X0.8 X0.10 X0.12 X0.14 S/S -
TB2 X0.1 X0.3 X0.5 X0.7 X0.9 X0.11 X0.13 X0.15 S/S -
 Wiring the External Terminal Module UB-10-OR16B
For cables that can only be connected to the cables of group #1, see below.
Output form
Relay
Output voltage
Less than 250 VAC, 30 VDC
Length
UC-ET010-24D(1M)(28AWG)
UC-ET020-24D(2M)
UC-ET030-24D(3M)
(28AWG)
(28AWG)
Length:
39 40
1 2
500+10mm
-
19 20
1 2
19 20
1
2
#1
#2
C0 Y0 .5Y0.0 Y0.1 Y0.2 Y0.3 C1 Y0.4 Y0.6 C3Y0.7
C2
Y0.8 Y0.9 Y0.10 Y0.11
Y0.12
Y0.14
Y0.15Y0.13
GND
+24V
