5V differential output encoder
Z-
A+
A-
B-
B+
Z+
MPG
Phase
A
Phase
B
Phase
Z
AS02H C-A
4.11.3.2 SSI Input / Output Encoder
DATA-
+5V
GND
CLK-
CLK+
DATA+
SSI encoder
Shield cable
AS02HC-A
+V
0V
DATA-
CLK-
CLK+
DATA+
Note: The power supply of the SSI encoder you are using may NOT be 5 VDC, check for the actual
power supply of your SSI encoder.
