Delta AS Series User Manual

Classification Model Name Description
2-channel analog output
Hardware resolution: 12 bits
-10 to +10V, 0–20mA, 4–20mA
Conversion time: 2 ms/channel
AS02ADH-A
2-channel analog input
Hardware resolution: 16 bits
0–10V, 0/1–5V, -5 to +5V, -10 to +10V, 0/4–20mA, -20 to
+20mA
High-speed conversion time: 20 µs
The analog channels are isolated from one another.
Digital output value (2000 per channel), peak value
Low-pass and band-pass filters are available.
Temperature
measurement
module
AS04RTD-A
4-channel, 2-wire/3-wire RTD
Sensor type: Pt100 / Ni100 / Pt1000 / Ni1000 / JPt100 / LG-
Ni1000 / Cu50 / Cu100 / 0-300Ω / 0-3000Ω / Ni120 (FW
V1.06 or later) input impedance
Resolution: 0.1°C/0.1°F (16 bits)
Conversion time: 200ms/channel
AS06RTD-A
6-channel, 2-wire/3-wire RTD
Sensor type: Pt100 / Ni100 / Pt1000 / Ni1000 / JPt100 / LG-
Ni1000 / Cu50 / Cu100 / 0-300Ω / 0-3000Ω / Ni120 (FW
V1.06 or later) input impedance, Resolution: 0.1°C/0.1°F
(16 bits)
Conversion time: 200ms/channel
AS04TC-A
4-channel thermocouple
Sensor type: J, K, R, S, T, E, N, B and -100 to +100 mV
Resolution: 0.1°C/0.1°F (24 bits)
Conversion time: 200ms/channel
AS08TC-A
8-channel thermocouple
Sensor type: J, K, R, S, T, E, N, B and -100 to +100 mV
Resolution: 0.1°C/0.1°F (24 bits)
Conversion time: 200ms/channel
Load cell
AS02LC-A 2-channel, 4-wire/6-wire load cell sensor
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
