Delta AS Series - Page 409

Item
AS300 AS200 / AS100 AS-FEN02
Scanner Adapter Scanner Adapter Adapter
Ethernet Link Object (16#F6)
CIP Network
Tag
Max. Consumed Tag
Number
32 16
N/A
Max. Produced Tag
Number
32 16
Max. Data Length
500 bytes (IO Connection)
400 bytes (Explicit Message)**
Requested Packet
Interval (RPI)
5 ms – 1000 ms
Maximum number of connections when using AS300 to connect to other devices through Ethernet/IP:
 AS300 can act as a Scanner and an Adapter simultaneously. It can connected up to 16 devices (for example 8
Scanners and 8 Adapters).
 When AS300 acts as a Scanner, it can connect to up to 16 devices. Each device can establish up to 32
connections for data exchange. Data exchange types can be I/O connection and Consumed Tag. You can use
explicit message for data exchange at the same time, up to 16 explicit message connections can be created.
 When AS300 acts as an Adapter, it can connect to up to 16 devices. Each device can establish up to 8
connections for data exchange. Data exchange types can be I/O connection and Produced Tag. You can use
explicit message for data exchange at the same time, up to 8 explicit message connections can be created.
* Using device D or device M takes 2 bytes (16 bits) as a unit in data length for IO connections, for example M0 to M15
(16 bits), M12 to M43 (32 bits). If you need to store the data of 200 bits from M100, the data length should be set in a
value larger than 200 bits and in bytes it will be 26 bytes (26 bytes = 208 bits), the actual devices to be mapped will be
M100 to M307. D0.0 will be stored in M100 (the first bit).
** Array-typed tags are NOT supported in explicit messages.
