Create
Projec tISPSoft
Open
HWC ONFI G
Set up
IP Address
Dow nload
HWC ONFI G
9.4.2.2 Set the IP Address (Static IP)
Steps to set the IP address
When using an EIP product with a static IP address, set up the IP address in HWCONFIG in ISPSoft. The following
example uses the AS Series.
1. Configure the network parameters
Double-click the AS Series module in HWCONFIG to see the Edit Area.
On the Ethernet Port Basic Setting tab, set the IP address and then click OK.
2. Save and download the settings from HWCONFIG: on the File menu click Save to save the settings and then
click Download button on the toolbar.
