Delta AS Series User Manual

Data Type Description
Spanish s p a
Italian i t a
STRUCT
STRUCT of: Composed of any data types.
Ex.: STRUCT of { BOOL, UINT, DINT } = { TRUE, H’1234, H’56789ABC }
1st 2nd 3rd 4th 5th 6th 7th
Byte 01 34 12 BC 9A 78 56
ARRAY
Array of: Composed of one data type.
Ex.: ARRAY of UINTs = { 1，2，3 }
Number 1st 2nd 3rd 4th 5th 6th
Array 01 00 02 00 03 00
EPATH
A path that consists of multiple segments and references the class, instance and attribute of
another object.
Example：Identity Object, Instance attribute 5 = “ 20 01 24 01 30 05 “
