Delta AS Series User Manual

H’02 Max Instance Get UINT H’C7
The maximum number of
instances
 When Instance = 64–87, the Instance Attributes are listed below. (Length of input and output is editable. The
maximum length is 250 words; supports only even bytes)
I/O Message Connection
Connection No. Function Instance Attribute Length
Connection 1
Input (TO) 0x65 D1000~D1099
Output (OT) 0x64 D0~D99
Configuration 0x80 Refer to the table below
Connection 2
Input (TO) 0x67 D1100~D1199
Output (OT) 0x66 D100~D199
Configuration 0x81 Refer to the table below
Connection 3
Input (TO) 0x69 D1200~D1299
Output (OT) 0x68 D200~D299
Configuration 0x82 Refer to the table below
Connection 4
Input (TO) 0x6B D1300~D1399
Output (OT) 0x6A D300~D399
Configuration 0x83 Refer to the table below
Connection 5
Input (TO) 0x6D D1400~D1499
Output (OT) 0x6C D400~D499
Configuration 0x84 Refer to the table below
Connection 6
Input (TO) 0x6F D1500~D1599
Output (OT) 0x6E D500~D599
Configuration 0x85 Refer to the table below
Connection 7
Input (TO) 0x71 D1600~D1699
Output (OT) 0x70 D600~D699
Configuration 0x86 Refer to the table below
Connection 8
Input (TO) 0x73 D1700~D1799
Output (OT) 0x72 D700~D799
Configuration 0x87 Refer to the table below
