Delta AS Series - Page 513

Item Description
Table name
Name of the table; read only
Monitor status
Status of the monitoring; read only
Yellow light: reading, Green light: reading complete, Red light: reading error
Update cycle
Update cycle time; default is what you set up in data monitor setup page; unit:
second
“-“
Minus; click once to decrease 1; the minimum value is 1
“+“
Plus; click once to increase 1; the maximum value is 60
Floating format
setting
Floating point setting; round down; default: round the number down to three
decimal places
Device
Devices to be monitored; read only
Radix
Positional numeral system to be shown on the monitoring page; available formats
are Signed decimal, Unsigned decimal, Hexadecimal, Octal, Binary, 32bit Signed
decimal, 32bit Unsigned decimal, 32bit Hexadecimal, 32bit Octal, 32bit Binary,
32bit Float and 64bit Double
Description
Add a description here for the table; read only
Status
Status of bit; read only
Green LED: ON; No LED: OFF
Value
Values in devices to be monitored; read only
Signed decimal: K+ Number
Unsigned decimal: K+ Number
Hexadecimal: H + hex Number
Octal: O + octal Number
Binary: B + binary Number
32bit Signed decimal: K+ Number
32bit Unsigned decimal: K+ Number
32bit Hexadecimal: H + hex Number
32bit Octal: O + octal Number
32bit Binary: B + binary Number
32bit Float: float Number
64bit Double: float Number
“On” / ”Off”
“ON”: the status of Bit is ON.
“OFF”: the status of Bit is OFF.
 If the authority level for the logged in user is READ, this column is read only.
Set Value
Change the value for the device to be monitored
 Type the value in and click “SET” and the changed value appears in the
VALUE column as the image shown above.
 If the authority level for the logged in user is READ, this column is read only.
“Set”
Click “Set” to confirm the changed value.

If the authority level for the logged in user is READ, this column is read only.
