Delta AS Series User Manual

 AS02ADH-A
Electrical specifications
Supply Voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Connector Type
Removable terminal block
Isolation
An analog circuit is isolated from a digital circuit by a digital integrated circuit/
optocoupler, but the analog channels are not isolated from one another.
Isolation between a digital circuit and a ground: 500 VAC
Isolation between an analog circuit and a ground: 500 VAC
Isolation between an analog circuit and a digital circuit: 500 VAC
Isolation between the 24 VDC and a ground: 500 VAC
Rated voltage of external
input point
24 VDC
Rated currentof external
input point
5 mA
Resistance value of
external input point
3.9 kΩ
Hardware response time
of external input point
OFF -> ON
< 5 µs
Hardware response time
of external input point
ON -> OFF
< 5 µs
Weight
154 g
Functional specifications
Number of input channels
2
Analog input
Voltage: -10 V to 10 V, 0 V to 10 V, 5 V to -5 V, 0 V to 5 V, 1 V to 5 V
Current: -20 mA to 20 mA, 0 mA to 20 mA, 4 mA to 20 mA
Digital output
16-bit integer
32-bit floating point
Error rate
Room temperature: ±0.1% ; full temperature range: ±0.2%
Hardware resolution
16 bits
Input resistance value
Voltage: ≧2 MΩ
Current: 250 Ω
Absolute input range
*1
Voltage: ±15 V
Current: ±32 mA
Channel sampling
Cycle
*2
20 µs, 40 µs and 80 µs
Bandwidth of analog
input signal
20 kHz
Average function
Time average, moving average: 1 to 1000 times
Digital filtering
Low-pass filter, band-pass filter
Logging function*
3
Digital output value (2000 per channel), peak value
Digital calibration
Maximum / minimum digital output value clipping, gain, offset
Abnoraml input signal
detection
Limit-exceeding detection, disconnection detection
#4
External input triggering
2 points (1 point / channel), rising-edge or falling-edge triggered
Maximum frequency of
external input point
triggering
10 kHz
*1: If an input signal exceeds the absolute range, it might damage the channel.
*2: Two channels are in A/D conversion simulanelously.
