AX-Series Motion Controller Instructions Manual Chapter 2
463
Name Function Data Type
Setting Value
(Default Value)
Timing to Take
Effect
RollDiameter
Source
Roll diameter source
R2R_ROLL_DIAMET
ER_SOURCE
*1
0:
R2R_Run_lrLineSpeedVal
ue
1: AVI
2: ACI
3:
ThicknessIntegrate_Motor_
Encorder_PG1
4:
ThicknessIntegrate_Motor_
Encorder_PG2
5:
ThicknessIntegrate_Motor_
Encorder_MI67
6:
ThicknessIntegrate_Motor_
CloseSW_MI7
7:
ThicknessIntegrate_Windin
g_
Encorder_PG2
8:
ThicknessIntegrate_Windin
g_
Encorder_MI67
9:
ThicknessIntegrate_Windin
g_
CloseSW_MI7
(LineSpeed)
When bExecute turns
to True and bBusy is
False
lrRollDiamete
rStart
Current roll diameter (mm) LREAL
1.0~6000.0
(6000.0)
When bExecute turns
to True and bBusy is
False
lrRollDiamete
rMax
Maximum roll diameter
(mm)
LREAL
1.0~6000.0
(6000.0)
When bExecute turns
to True and bBusy is
False
lrRollDiamete
rMin
Empty roll diameter (mm) LREAL
1.0~6000.0
(1.0)
When bExecute turns
to True and bBusy is
False
uiPulsePerRe
volution
Number of pulses per
revolution (Pulse/lr)
UINT
1~60000
(1)
When bExecute turns
to True and bBusy is
False
uiRoundPerL
ayer
Number of rounds per layer
(round/layer)
UINT
1~10000
(1)
When bExecute turns
to True and bBusy is
False
MaterialThick
nessUnit
Material thickness multiple
R2R_MATERIAL_THI
CKNESS_GAIN
*2
0:
millimeter
1: centimeter
(millimeter)
When bExecute turns
to True and bBusy is
False
lrMaterialThic
kness
Material thickness (mm) LREAL
0.001~65.0
(0.001)
When bExecute turns
to True and bBusy is
False
lrRollDiamete
Roll diameter filter time (s) LREAL 0~100.0 When bExecute turns
