AX-Series Motion Controller Instructions Manual Chapter 2

186

2.3.1.5 DMC_MoveCircularAbsolute

 Supported Devices: AX-308E, AX-364E

DMC_MoveCircularAbsolute controls the axis group to perform circular or helical interpolation for a specified absolute target

position.

FB/FC Instruction Graphic Expression

FB DMC_MoveCircularAbsolute

ST Language

DMC_MoveCircularAbsolute_instance(

AxisGroup: = ,

bExecute: = ,

CircPlane: = ,

CircMode: = ,

AuxPoint: = ,

EndPoint: = ,

PathChoice: = ,

dwSpiralTurns: = ,

lrVelocity: = ,

lrAcceleration: = ,

lrDeceleration: = ,

lrJerk: = ,

CoordSystem: =,

BufferMode: = ,

TransitionMode: = ,

bDone=> ,

bBusy=> ,

bActive=> ,

bCommandAborted=> ,

bError=> ,

ErrorID=> ;
