93
Step 6
Set the new memory backup battery ready for use in Step 2 on the battery cover.
Step 7
Connect the backup battery harness to the controller.
Step 8
Mount the battery cover with the new backup battery into the controller and secure
the cover with the screw.
Caution Take care not to pinch the battery lead wires between covers or
internal parts. Shorting may occur, resulting in an unexpected
failure.
To Next Page
