7.5.8 Parallel I/O Board (2nd) in All User I/O Mode
T
erminal
No.
Signal Name
Port
No.
Direction
Te rminal
No.
Signal Name
Port
No
Direction
1 3888 OUT 49 3912 OUT
2 3889 OUT 50 3913 OUT
3 3890 OUT 51 3914 OUT
4 3891 OUT 52 3915 OUT
5 3892 OUT 53 3916 OUT
6 3893 OUT 54 3917 OUT
7 3894 OUT 55 3918 OUT
8 3895 OUT 56 3919 OUT
9 3896 OUT 57 3920 OUT
10 3897 OUT 58 3921 OUT
11 3898 OUT 59 3922 OUT
12 3899 OUT 60 3923 OUT
13 3900 OUT 61 3924 OUT
14 3901 OUT 62 3925 OUT
15 3902 OUT 63 3926 OUT
16 3903 OUT 64 3927 OUT
17 3904 OUT 65 3928 OUT
18 3905 OUT 66 3929 OUT
19 3906 OUT 67 3930 OUT
20 3907 OUT 68 3931 OUT
21 3908 OUT 69 3932 OUT
22 3909 OUT 70 3933 OUT
23 3910 OUT 71 3934 OUT
24
User output
3911 OUT 72
User output
3935 OUT
25 3624 IN 73 3644 IN
26 3625 IN 74 3645 IN
27 3626 IN 75 3646 IN
28 3627 IN 76 3647 IN
29 3628 IN 77 3648 IN
30 3629 IN 78 3649 IN
31 3630 IN 79 3650 IN
32 3631 IN 80 3651 IN
33 3632 IN 81 3652 IN
34 3633 IN 82 3653 IN
35 3634 IN 83 3654 IN
36 3635 IN 84 3655 IN
37 3636 IN 85 3656 IN
38 3637 IN 86 3657 IN
39 3638 IN 87 3658 IN
40 3639 IN 88 3659 IN
41 3640 IN 89 3660 IN
42 3641 IN 90 3661 IN
43 3642 IN 91 3662 IN
44
User input
3643 IN 92
User input
3663 IN
45
Power +24V
⎯
IN 93
Power 0V ⎯
IN
46
Power +24V
⎯
IN 94
Power 0V ⎯
IN
47
Power +24V
⎯
IN 95
Power 0V ⎯
IN
48
Power +24V
⎯
IN 96
Power 0V ⎯
IN
