Denso RC7M User Manual

124
7.5.19 CC-Link Board (3 stations occupied) in All User I/O Mode
Input data Output data
Port
No.
Signal name
Remote
output.
(Note 1)
Port
No.
Signal name
Remote
input
(Note 1)
512 INPUT 512 RYn0 768 OUTPUT 768 RXn0
513 INPUT 513 RYn1 769 OUTPUT 769 RXn1
514 INPUT 514 RYn2 770 OUTPUT 770 RXn2
515 INPUT 515 RYn3 771 OUTPUT 771 RXn3
516 INPUT 516 RYn4 772 OUTPUT 772 RXn4
517 INPUT 517 RYn5 773 OUTPUT 773 RXn5
518 INPUT 518 RYn6 774 OUTPUT 774 RXn6
519 INPUT 519 RYn7 775 OUTPUT 775 RXn7
520 INPUT 520 RYn8 776 OUTPUT 776 RXn8
521 INPUT 521 RYn9 777 OUTPUT 777 RXn9
522 INPUT 522 RYnA 778 OUTPUT 778 RXnA
523 INPUT 523 RYnB 779 OUTPUT 779 RXnB
524 INPUT 524 RYnC 780 OUTPUT 780 RXnC
525 INPUT 525 RYnD 781 OUTPUT 781 RXnD
526 INPUT 526 RYnE 782 OUTPUT 782 RXnE
527 INPUT 527 RYnF 783 OUTPUT 783 RXnF
528 INPUT 528 RY(n+1)0 784 OUTPUT 784 RX(n+1)0
529 INPUT 529 RY(n+1)1 785 OUTPUT 785 RX(n+1)1
530 INPUT 530 RY(n+1)2 786 OUTPUT 786 RX(n+1)2
531 INPUT 531 RY(n+1)3 787 OUTPUT 787 RX(n+1)3
532 INPUT 532 RY(n+1)4 788 OUTPUT 788 RX(n+1)4
533 INPUT 533 RY(n+1)5 789 OUTPUT 789 RX(n+1)5
534 INPUT 534 RY(n+1)6 790 OUTPUT 790 RX(n+1)6
535 INPUT 535 RY(n+1)7 791 OUTPUT 791 RX(n+1)7
536 RY(n+1)8 792 OUTPUT 792 RX(n+1)8
: : 793 OUTPUT 793 RX(n+1)9
591
User input (INPUT m)
(Note 2)
RY(n+4)F 794 OUTPUT 794 RX(n+1)A
592 RY(n+5)0 795 OUTPUT 795 RX(n+1)B
: : 796 OUTPUT 796 RX(n+1)C
607
Not used.
RY(n+5)F 797 OUTPUT 797 RX(n+1)D
798 OUTPUT 798 RX(n+1)E
799 OUTPUT 799 RX(n+1)F
800 RX(n+2)0
: :
847
User output (OUTPUT m)
(Note 2)
RX(n+4)F
848 RX(n+5)0
: :
857
Not used.
RX(n+5)9
858 Error status flag RX(n+5)A
859 Remote station ready RX(n+5)B
860 RX(n+5)C
: :
863
Not used.
RX(n+5)F
Note 1: n denotes (station number − 1) × 2 (hexadecimal notation).
Note 2: m denotes I/O port number.
Note 3:
indicates the system area that cannot be used for user I/O.
