VENUE Profile Guide4
VENUE Mix Rack System
VENUE Profile Console with Mix Rack
Mix Rack Features
The Mix Rack provides all stage and mix position I/O for
VENUE Mix Rack systems.
Stage I/O
• 48 inputs with mic preamps. Each fully recallable input
provides phantom power and input gain.
• 16 line level analog outputs (expandable up to 32) to
connect to mains and monitors.
FOH I/O
• 8 pairs of analog I/O for hardware inserts, or for input
and output of line-level material from the mix position.
• Analog and digital (AES or S/PDIF) 2-Track inputs and
outputs.
• Com mic input, with gain control and phantom power.
• Monitor outputs for mix position near field monitors.
Synchronization and Control I/O
• MIDI In and Out ports, providing 16 channels of MIDI
input and 16 channels of MIDI output.
• Word clock I/O for digital clock synchronization.
• USB 2.0 ports for USB disks, iLoks, and other USB devices.
• 100 BaseT Ethernet (ECx) port for remote control.
CPU, DSP, and System Drives
Mix Rack houses the CPU, DSP, hard drive and CD-ROM drive
that run the VENUE D-Show software on your VENUE system.
System software is installed at the factory. The CD-ROM drive
lets you update or restore your system software, and install
compatible plug-ins from their installer discs. A standard
Mix Rack includes two Mix Engine cards providing DSP for
plug-ins. You can add one additional Mix Engine card, for a
maximum of three.
Redundant Power Supply Units (PSUs)
Each Mix Rack comes with two universal (100V to 240V nom-
inal, 50–60 Hz) PSUs with auto redundant failover and LED
status indication.
VENUE Profile System
VENUE Profile Console with FOH Rack and Stage Rack
FOH Rack Features
The FOH Rack is used with one or more Stage Racks, and pro-
vides mix position I/O for VENUE Profile systems.
Audio I/O
• 8 pairs of analog I/O for hardware inserts, or for input
and output of line-level material from the mix position.
• Analog and digital (AES or S/PDIF) 2-Track inputs and
outputs.
• Monitor outputs for mix position near field monitors.
• Intercom mic input
Synchronization and Control I/O
• MIDI In and Out ports, providing 16 channels of MIDI
input and 16 channels of MIDI output.
• Word clock I/O for digital clock synchronization.
• USB 2.0 ports for USB disks, iLoks, and other USB devices.
• 100 BaseT Ethernet (ECx) port for Ethernet-based remote
control.
• Snake connectors to enable primary and redundant (if
applicable) connection to the VENUE Stage Rack.
CPU, DSP, and System Drives
FOH Rack houses the CPU, DSP, hard drive and CD-ROM drive
that run the VENUE D-Show software on your VENUE system.
System software is installed at the factory. The CD-ROM drive
lets you update or restore your system software, and install
compatible plug-ins from their installer discs. A standard
FOH Rack includes three Mix Engine cards, which provide
DSP for plug-ins and mixing. You can add up to two addi-
tional Mix Engine cards, up to a maximum of five.
Redundant Power Supply Units (PSUs)
Each FOH Rack comes with two universal (100V to 240V nom-
inal, 50–60 Hz) PSUs with auto redundant failover and LED
status indication.
