VENUE Profile Guide82
Output Mute
To control the mute status of an output bus:
1 Bank the Output faders to the desired type of output:
2 In the Output section, press a Mute switch to toggle the
mute status of the corresponding output bus.
For more information on Mute operation, see Chapter 15,
“Muting and Mute Groups.”
Output Delay
A variable delay can be applied to any of the Main busses (L, R
and C/M), Aux bus outputs, and Matrix mixer outputs. (Vari-
able Group outputs do not have this variable delay feature.)
To apply delay to an Aux bus:
1 Target the Aux bus by pressing its Select switch.
2 Press the ACS Delay rotary encoder to engage the delay.
3 Adjust the delay value by turning the Delay rotary encoder.
The amount of delay available depends on the type of output,
as follows:
• Up to 500 ms for Mains and Matrix mixers
• Up to 250 ms for Aux Sends
Adjusting Main Bus Controls
Mains Bus Output Levels
The Mains bus output levels are controlled from the single
Mains Fader located to the right of the Output faders.
The Left, Right, and Center/Mono busses can be controlled in-
dependently or in tandem. You can create an offset between
any of the Main bus levels, and it will be preserved when con-
trolling any combination of the Main busses. The offset be-
tween the busses is maintained until at least one of the busses
is minimized or maximized.
Linking Mains
You can link any of the three Mains faders for grouped-control
of level and mute.
To link control of the Mains bus output levels:
1 In the Outputs page, click the on-screen channel Link but-
tons for any combination of Left, Right, or Center/Mono out-
put strips to assign control of the corresponding busses to the
Mains Fader.
2 Move the Mains fader to change the level of the assigned
busses.
Mains Bus Mute
The mute status of the Main busses is controlled from the
Mute switch located above the Mains Fader. When at least one
of the Main busses is muted while others (unlinked) are not,
the Mains mute switch flashes.
To control the mute status of the Main busses:
1 In the Outputs page, click the on-screen channel Link but-
tons for any combination of Left, Right, or Center/Mono out-
put strips to assign control of the corresponding busses to the
Mains Fader.
2 Press the Mute switch to toggle the mute status of the as-
signed busses.
Mains Fader and controls in the Output section
Mains fader Link selectors in the Outputs page
