Chapter 2: Configuring and Connecting Profile 15

Connections for VENUE Profile Systems

This section describes system and audio connections for FOH Rack and Stage Rack systems. (For VENUE Mix Rack systems, see

“Connections for VENUE Mix Rack Systems” on page 12).

Figure 5. VENUE Profile system component connections

VENUE Profile

FOH Rack (Front)

FOH Rack (Back)

Stage Rack (Front)

FOH Link Cable

Digital Snake Cables

Primary Snake

Redundant Snake

Default Chapter5
