VENUE Profile Guide40
Fine Switch
The Fine (Ctrl) switch lets you adjust controls (except for fad-
ers) on the console or on-screen with maximum resolution.
For example, if by default a control adjusts a parameter in
units of 1 dB, the Fine switch allows adjustment in units of
0.1 dB.
To adjust a control with fine resolution:
ī Press and hold the Fine switch while moving a control. The
display associated with the adjusted control will show the val-
ues change at the corresponding resolution.
Momentary and Latching Modes
The Fine switch supports momentary and latching operation.
Momentary In momentary mode, the Fine switch stays in ef-
fect for as long as you hold down that modifier switch.
Latching In latching mode, the Fine switch stays in effect until
you explicitly clear its active state.
To use the Fine switch in Momentary mode:
1 Press and hold the Fine switch.
2 Adjust a channel, parameter, or processor.
3 Release the Fine switch.
To use the Fine switch in latching mode:
1 Double-press the Fine switch. The switch LED lights.
2 Select or adjust one or more channels, parameters, or pro-
cessors.
3 Press the Fine switch again to exit latching mode.
User
The User switch is reserved for future use.
Software Screen Pages and Tabs
Viewing Pages
To view a page, do one of the following:
ī Press a View Mode switch.
ā or ā
ī Click the page name at the top of the screen.
When additional tabs are available for a page, go to those tabs
by pressing the corresponding View Mode switch again to
cycle through the tabs on that page, or by clicking their names
on-screen.
Viewing pages
Click page name to display
