IntroductionModel 2500 16
© 2015-2017 Distek, Inc. All Rights Reserved
1.5.1 Physical Site Consideration
The dimensional requirements specified below are adequate for the installation of the Model 2500
Dissolution System:
1 The minimum bench depth needed (front edge of bench to the back splash or wall) is 22
inches (56cm). However, the minimum recommended bench depth is 25 inches (64cm) for
proper ventilation.
2 The minimum linear bench space requirement is 28 inches (71cm). Distek recommends
that at least 33 inches (84cm) be allocated whenever manual operations are required to be
performed adjacent to the system.
3 There must be no obstruction (cabinet, shelf, or outlet) that intrudes into the minimum
footprint of the unit up to a height of 39 inches (99cm) above the bench surface where the
unit is to be installed.
4 The bench must be capable of sustaining the weight of the unit and all of its accessory
parts without significant bending. Because the entire mass of the unit is transferred to the
bench surface through four (4) circular padded, adjustable leveling feet, the bench surface
should be strong enough to withstand a load of 60 pounds per square inch (4 kilograms per
square centimeter).
5 Because of the limitation in travel of the leveling feet, the bench slope should be less than
0.75” (1.9cm) from front to back or from side to side over the unit’s foot print.
