IntroductionModel 2500 17
© 2015-2017 Distek, Inc. All Rights Reserved
1.5.2 Electrical Requirements
Your instrument can operate on line voltage of 115V ± 15V 50/60Hz or
230V ± 15V 50/60Hz . Since
the instrument is pre-configured for either 115 VAC or 230 VAC, there is no voltage selector and
no external accessible fuses to replace. Refer to Instrument Specification regarding the current
rating depending on the number of modules or positions of the instrument.
To disconnect the instrument from the line, pull out the power cord. The power supply still
stores some power, even if the power switch is turned off or the power cable is unplugged.
Other accessories, such as printers, accept nominal line voltage of 115 or 230 VAC at 50 or 60 Hertz.
For more information, see the documentation that came with your accessories.
Do not connect your instrument to a line voltage that is higher than the specified voltage.
Shock hazard or damage to your instrument can occur.
Power cords are offered in different configurations depending on the particular country or region
of intended use. For all cables, the female end of the supplied power cord is identical and it
plugs into the power inlet socket located on the right side of the instrument. The male end of
each supplied power cord is different and designed to match the wall outlet of the intended
country or region of use.
Always use the power cord supplied with your instrument. Always plug in your instrument
with a properly grounded wall outlet.
