3.1 TempChek
The TempChek is an ultra-high accuracy resolution, hand-held digital thermometer that uses a YSI
series precision thermistor. Along with an RS-232 port, it allows temperature data from the
TempChek to be sent to the Model 2500 to calibrate the TCS temperature sensors and or the RTD
wireless shafts.
Installing the TempChek
1 Using a male to female standard 9 pin RS-232 cable, connect one end of the cable to the
TempChek and the other end to Model 2500 RS-232 side port.
2 Follow the calibration procedure "Using Distek TempChek".
TempChek Connected to Model 2500 via RS-232
