InstallationModel 2500 33
© 2015-2017 Distek, Inc. All Rights Reserved
2.6.1 Standard Shafts
To install the shafts, follow the procedure below:
1 Raise the drive unit.
Remove the shaft collar from the shaft.
From the bottom of the spindle, insert a shaft in each spindle position.
Shaft installation
2 Install the shaft collars on the top end of each shaft and leave them loose.
Shaft collar
