Instructions for use Carina SW 3.2n 61
Getting started
After the device check
Switch Carina to standby mode, see page 77.
6 Check the Airway pres-
sure low !!! alarm
Confirm the Airway pressure
high !!! alarm.
Disconnect the test lung from
the breathing circuit.
Optical alarm signals:
The Airway pressure low
!!! alarm message is dis-
played and the Audio
paused 2 min. alarm LED
flashes red.
Acoustic alarm signal: High-
priority alarm signal
7 Check apnea ventilation Connect the test lung to the
breathing circuit.
Set the ventilation mode:
SPN-CPAP/PS
After the apnea alarm time
has elapsed:
Optical alarm signals:
The Apnea Ventilation !
alarm message is displayed
and the Audio paused
2min. alarm LED lights yel-
low.
Acoustic alarm signal: Low-
priority alarm signal
Setting alarm limits:
Paw high:
Tapn:
45 mbar
5s
Setting ventilation parameters:
Apn.Vent.:
Pmax:
VTapn:
On
40 mbar
500 mL
Simulate spontaneous breath-
ing by squeezing the test lung.
Then stop the breathing.
After a successful device check, Carina is ready for use with the patient.
Test step Measure Requirement Result
