Dräger Carina

Instructions for use Carina SW 3.2n 93
Configuration
Selecting the application mode
The application mode can only be selected in
standby mode. The NIV application mode can only
be selected if LeakV is displayed in the status line
on the screen.
Prerequisite: The Config. menu is opened.
1 Press the key.
2 In menu 2 press the Method key.
3 Select NIV or Tube by turning the rotary knob
and push to confirm.
The selected application mode is displayed in the
status line of the screen.
Selecting the O2 supply
The O2 supply can only be set in standby mode.
Prerequisite: The Config. menu is opened.
1 Press the key.
2 In menu 2 press the O
2 suppl. key.
3 Select LPO or HPO by turning the rotary knob
and push to confirm.
If LPO has been selected, LPO is displayed in the
status line on the screen.
Selecting Ti or I:E
Prerequisite: The Config. menu is opened.
1 Press the key.
2 In menu 2 press the Ti / I:E key.
3 Select Ti or I:E by turning the rotary knob and
push to confirm.
