Configuration
92 Instructions for use Carina SW 3.2n
Screen display Curves
A Flow waveform in real time
B Pressure waveform in real time
C Value 1 field, configurable measured-value dis-
play
D Value 2 field, configurable measured-value dis-
play
Measured values screen display
A Pressure waveform as bar graph
B 4 Fields for measured values:
– MVi (MV)
–VTi (VT)
–RR
–PIP
C Value 1 field, configurable measured-value dis-
play
D Value 2 field, configurable measured-value dis-
play
Configuring the display for measured
values
The following measured values can be selected for
the Value 1 and Value 2 fields:
– Off (no display of a measured value)
–PIP
–VTi (VT)
–RR
– PEEP
–MVi (MV)
–MVleak
–Pmean
–Tadpt
It is not possible to select the same measured val-
ues for Value 1 and Value 2.
Selecting measured values
Prerequisite: The Config. menu is opened.
1 Press the key.
2 In menu 2 press the Set value button.
3 Press the Value 1 key.
4 Select the measured value by turning the rotary
knob and push to confirm.
5 Select the measured value for Value 2 in the
same way.
