Dräger Carina

Instructions for use Carina SW 3.2n 127
Technical data
2165619 breathing hose with 8412217 hu-
midifier chamber, 2 x 2165627 breathing
hose, 8404985 water trap and MP00224
leakage valve
<2 mbar (or hPa or cm H
2O)
2165619 breathing hose with 8412217 hu-
midifier chamber, 2 x 2165627 breathing
hose, 8404985 water trap and MP00220
expiratory valve
<2 mbar (or hPa or cm H2O)
Safety valve Opens breathing system in case of fault
Safety valve (overpressure) Restricts the airway pressure to 60 mbar (or hPa or
cm H
2O)
Emergency breathing valve (underpressure) Restricts the airway pressure to –3 mbar (or hPa or
cm H
2O)
Displayed measured values
Peak inspiratory pressure PIP
Range 0 to 68 mbar (or hPa or cm H
2O)
Resolution 1 mbar (or hPa or cm H
2O)
Accuracy ±(8 % of measured value +1.2 mbar) when using
MP00312, MP00313 breathing circuits (without
leakages)
Positive end-expiratory pressure PEEP
Range 0 to 25 mbar (or hPa or cm H
2O)
Resolution 1 mbar (or hPa or cm H2O)
Accuracy ±(8 % of measured value +1.2 mbar) when using
MP00312, MP00313 breathing circuits (without
leakages)
Inspiratory tidal volume VTi, VT
Range 0 to 4.0 L, BTPS
Resolution 1 mL
Accuracy ±10 % of measured value or ±20 mL, whichever is
greater (without leakage, and taking account of
hose compliance correction, "Volume losses during
ventilation" on page 144)
Performance characteristics (cont.)
