Setting ranges for ventilation
Ventilation
parameter
Ventilation mode
VC-SIMV VC-AC PC-BIPAP PC-AC SPN-CPAP/PS
(VG)
VT
1)
[mL]
1) For SPN-CPAP/PS the following applies: Only with activated Volume Guarantee VG.
100 to 2000 100 to 2000 – – 100 to 2000
Pinsp
2)
[mbar,
cm H2O]
2) For PC-BIPAP and PC-AC the following applies: Only Pinsp values that are at least 2 mbar above the set PEEP value can
be set.
– – LeakV: 5 to 40
ExpV: 5 to 50
LeakV: 5 to 40
ExpV: 5 to 50
–
PEEP [mbar,
cm H
2O]
3 to 20 3 to 20 3 to 20 3 to 20 3 to 20
FiO
2
3)
[%]
3) Only with HPO O2 supply.
21 to 100 21 to 100 21 to 100 21 to 100 21 to 100
Trigger Off, Normal,
Sensitiv.
Off, Normal,
Sensitiv.
Off, Normal,
Sensitiv.
Off, Normal,
Sensitiv.
Normal, Sensitiv.
RR [/min] 5 to 50 5 to 50 5 to 50 5 to 50 –
Ti
4)
[s]
or I:E
4) For VC-SIMV/PS and PC-BIPAP/PS the following applies: The maximum inspiratory time Timax for pressure-supported
breaths is derived from Ti, see page 150.
0.3 to 8
1:39 to 2:1
0.3 to 8
1:39 to 2:1
0.3 to 8
1:39 to 2:1
0.3 to 8
1:39 to 2:1
–
Ramp Auto/0.1 to 2.0 Auto/0.1 to 2.0 Auto/0.1 to 2.0 Auto/0.1 to 2.0 Auto/0.1 to 2.0
Pmax
5)
[mbar,
cm H2O]
5) For SPN-CPAP/PS (VG) the following applies: Only with activated apnea ventilation or activated Volume Guarantee VG.
LeakV: 5 to 40
ExpV: 5 to 50
LeakV: 5 to 40
ExpV: 5 to 50
– – LeakV: 5 to 40
ExpV: 5 to 50
ΔPsupp
6)
[mbar, cm H
2O]
6) For SPN-CPAP/PS the following applies: Only with deactivated Volume Guarantee VG. For PC-BIPAP and VC-SIMV the
following applies: only with trigger activated
LeakV: 0 to 37
ExpV: 0 to 47
– LeakV: 0 to 37
ExpV: 0 to 47
– LeakV: 0 to 37
ExpV: 0 to 47
Timax [s] – – – – 0.4 to 10.0
Apn.Vent. – – – – On, Off
RRapn
7)
[/min]
7) Only with apnea ventilation activated.
– – – – 5 to 50
VTapn
7)
[mL] – – – – 100 to 2000
VG – – – – On, Off
Aut.Adapt
8)
8) Only in NIV application mode with Volume Guarantee VG deactivated.
– – – – On, Off
Tadpt
9)
[min]
9) Only with Aut.Adapt function activated.
– – – – 5 to 120
PEEPadp
9)
[mbar, cm H
2O]
– – – – 3 to 20
ΔPSadpt
9)
[mbar, cm H
2O]
– – – – 0 to 37
