Monitoring
122 Instructions for use Fabius Tiro SW 3.n
Airway pressure monitoring
Parameter field and waveform window
for airway pressure
The following parameters are displayed in
numerical and graphical form in the parameter field
and in waveform window for the airway pressure:
A The positive end-expiratory pressure (PEEP)
indicates the airway pressure at the end of the
expiration in cmH
2O (hPa). The display range
is between 0 and 30 cmH
2O (0 and 30 hPa).
B The plateau pressure (PLAT) indicates the
airway pressure at the end of the inspiration in
cmH
2O (hPa). The display range is between 0
and 80 cmH
2O (0 and 80 hPa).
or
The mean airway pressure (MEAN) indicates
the average of all pressure values that were
recorded during a breath in cmH
2O (hPa). The
display range is between 0 and 50 cmH
2O (0
and 50 hPa).
C The peak pressure (PEAK) indicates the
highest pressure value of each breath in
cmH
2O (hPa). The display range is between 0
and 80 cmH
2O (0 and 80 hPa).
D Upper alarm limit
E Pressure threshold
F Pressure waveform
G Pressure threshold as a line
The pressure threshold is used for the
detection of apnea (disconnection) and
continuous pressure. If the pressure waveform
does not cross the pressure threshold either
from above or below, an alarm is sounded.
H Scale of the pressure waveform with display
range from 0 to 20, 0 to 50, or 0 to 100 cmH
2O
(0 to 20, 0 to 50, or 0 to 100 hPa). The scaling
is done automatically.
Pressure alarms in automatic ventilation
modes
If Fabius does not detect a breath in a specific time
period, the alarm APNOEA PRESSURE !! or
APNOEA PRESSURE !!! is triggered, see chapter
''Alarm – Cause – Remedy'' on page 152.
Pressure alarms in ManSpont
If Fabius does not detect a breath in a specific time
period, after 30 seconds the alarm APNOEA
PRESSURE !! with the priority CAUTION is
triggered. If this alarm is not remedied, the priority
increases after a further 30 seconds to WARNING.
21577
NOTE
Fabius can be configured by DrägerService or an
authorized local service partner so that the mean
airway pressure (MEAN) is displayed instead of
the plateau pressure (PLAT).
Volume Control
A
B
C
D
E
F
GH
