Dräger Fabius Tiro - Calibrating the Flow Sensor; Calibrating the O 2 Sensor

Instructions for use Fabius Tiro SW 3.n 127
Configuration
Calibrating the flow sensor
1 Press the Calibrate Flow Sensor softkey (A).
2 Follow the instructions on the screen.
At the start of the calibration, the instructions are
hidden and the following message is displayed
above the standby softkeys (B):
Flow Calibration in progress
After the calibration, one of the following two
messages are displayed above the standby
softkeys (B):
Flow Calibration completed - reconnect
expiratory hose
or
Flow Calibration Failed
Troubleshooting with failed flow calibration
 Repeat the calibration.
 Replace the flow sensor.
If the calibration continues to fail, contact
DrägerService or the authorized local service
partner.
Calibrating the O2 sensor
In order for the O2 sensor to be correctly
calibrated, it must be exposed to the ambient air
during the entire calibration.
To avoid leakage, remove the O
2 sensor from the
cover of the inspiratory valve. Seal the cover of the
inspiratory valve with the valve cover plug.
1 Press the Calibrate O2 Sensor softkey (A).
2 Follow the instructions on the screen.
At the start of the calibration, the instructions are
hidden and the following message is displayed
above the standby softkeys (B):
O
2 Calibration in progress
After the calibration, one of the following two
messages are displayed above the standby
softkeys (B):
O
2 Sensor Calibration completed - reinsert O2
sensor
or
O
2 Sensor Calibration Failed
21582
Standby
A
B
21582
Standby
A
B
