Dräger Fabius Tiro - Recommended Device Configuration

Instructions for use Fabius Tiro SW 3.n 33
Overview
Recommended device configuration
Configuration 1
–Fabius
– Breathing gas monitor (Vamos)
1 Connect the breathing gas monitor either to
COM1 or COM2
*
(A).
Configuration 2
–Fabius
– Multiparameter monitor with a COM connection
1 Connect monitor to COM 1 (B).
Configuration 3
–Fabius
– Gas analyzer (SCIO/Vamos)
– Multiparameter monitor with a COM connection
1 Connect monitor to COM 1 (C).
2 Connect the gas analyzer to connection
COM 2
*
(D).
20958
*optional
20958
A
A
B
B
21915
C
C
D
D
