Instructions for use Fabius Tiro SW 3.n 51
Operating concept
Color coding for anesthetic agents and medical gases
The standardized color coding specified in
ISO 5359 / ISO 32 / ISO 5360 is used for
anesthetic agents and medical gases.
The colors for O
2, Air, and N2O are adapted
according to locally applicable standards.
Screen colors (optional)
For improved visibility, Fabius displays the
following screen elements in different colors:
– Softkeys (default)
– Alarm messages (see chapter ''Alarm
priorities'').
– Virtual flow tubes (setting according to country-
specific gas color codes)
– Screen background (bright/dark)
The screen elements are only displayed in color if
the option "Color display" is activated.
