Vigor2760 Series User’s Guide
150
Start IP Address
Type the start IP address for Range and Subnet type.
Note: If you want to specify just a single IP address for
the object, you have to set the same IP address in the
fields of Start IP Address and End IP Address.
End IP Address
Type the end IP address if the Range type is selected.
Select – Click the button to choose an IP address from the
existed IP addresses.
Subnet Mask
Type the subnet mask if the Subnet type is selected.
MAC Address
Type the MAC address of the network card which will be
controlled if the MAC type is selected.
MAC Binding
This setting changes slightly based on the Type (Range,
Subnet and MAC) you choose.
If you choose Range as the type and check the box of
MAC Binding, you have to specify a MAC Address of
this router in the related field.
The router will inspect if the MAC address of the
incoming packets matches with the specified MAC
address or not. If not, the packet will be block.
If you choose Subnet as the type and check the box of
MAC Binding, you have to specify a MAC Address of
this router in the related field.
The router will inspect if the MAC address of the
incoming packets matches with the specified MAC
