Duplo DP-440 - Free Zoom

52
Free Zoom
You can set a zoom ratio between 50% and 500% in 1% steps.
IMPORTANT
• Select “FREE ZOOM” before starting platemaking.
•You cannot select “94% Reduction” at the same time as “FREE ZOOM”.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Proceed with steps 1 to 4 of the sequence described in “ Basic Printmaking” (
aa
aa
a page 32).
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Press (ZOOM) key.
A list of the zoom ratios is displayed on the LCD panel.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Press “CURSOR” keys to select “FREE ZOOM”, and then press (OK) key.
Each press of “CURSOR” keys moves to a different item and that item is displayed highlighted. The free zoom
ratio is set when the cursor is moved to “FREE ZOOM”.
Pressing (CANCEL) key redisplays the main screen.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
