SV-XPNDR-26X Installation, Configuration, and Testing
11-10 SkyView System Installation Guide - Revision K
to accomplish, but is more difficult in a composite or fabric skinned aircraft. In these cases a
metallic ground plane should be fabricated and fitted under the antenna.
As the ground plane is made smaller, the actual dimensions of the ground plane become more
critical, and small multiples of the wavelength should be avoided, as should circles. Rectangles
or squares are much less likely to create a critical dimension that resonates with the
transmissions. The smallest practical ground plane is a square around 120 mm per side; as the
size increases the performance may actually get worse, but will be better by the time the
ground plane is 700 mm on each side. Anything much larger than that size is unlikely to show
significant further improvement.
The thickness of the material used to construct the ground plane is not critical, providing it is
sufficiently conductive. A variety of proprietary mesh and grid solutions are available.
Heavyweight cooking foil meets the technical requirements, but obviously needs to be properly
supported.
Antenna Cable
The SV-XPNDR-262 is designed to meet Class 2 requirements with an allowance of 2 dB for loss
in the connectors and cable used to connect it to the antenna. The SV-XPNDR-261 is designed
to meet Class 1 requirements with the same 2 dB allowance. Excessive loss will degrade both
transmitter output power and receiver sensitivity.
Allowing 0.25dB loss for the connector at each end of the antenna cable assembly leaves an
allowance of 1.5dB maximum loss for the cable itself.
An acceptable cable:
Has less than 1.5 dB loss for the run length needed
Has a characteristic impedance of 50 Ohms
Has double braid screens or has a foil and braid screen
Once the cable run length is known, a cable type with low enough loss per metre that meets
the above requirements can be chosen. Longer runs require lower loss cable. Consider moving
the SV-XPNDR-26X closer to the antenna to minimize the losses in the antenna cable – subject
to the limits identified above, the SV-XPNDR-26X can be at any distance from the SkyView
display(s) without affecting performance in any way.
Note: Low loss cable typically uses foamed or cellular dielectrics and foil screens. These
make such cables especially prone to damage from too-tight bends or from momentary
kinking during installation. Once kinked, these cables do not return to full performance
when straightened.
The following table is a guide to the maximum usable lengths of some common cable types.
Actual cable loss varies between manufacturers, there are many variants, and the table is
therefore based on typical data. Use it as a guide only and refer to the manufacturer’s data
sheet for your specific chosen cable for accurate values.
