Appendix C: Wiring and Electrical Connections
17-10 SkyView System Installation Guide - Revision K
SV-EMS-220 Male
D37 Pin
EMS 37-pin Harness Wire
Color
Description
15
Red
+12 volts DC Auxiliary Power Output
16
Black
Signal Ground
17
Black
Signal Ground
18
White/Red
+5 volts DC Auxiliary Power Output
(Fuse limited to 500 mA)
19
White/Black
Fuel Flow Input 2
20
Orange/Brown
General Purpose Input 9
21
Orange/Blue
General Purpose Input 10
22
Purple/Yellow
Enhanced General Purpose Input 2
23
Purple/Green
General Purpose Input 3
24
Orange/Green
Amps+ Input
25
Orange/Purple
Amps- Input
26
Green/Red
Manifold Pressure Input
27
Open
General Purpose TC Input 1+
28
Open
General Purpose TC Input 1-
29
Yellow/Green
Optional External Alarm Light
30
Black
Signal Ground
31
White/Orange
Enhanced General Purpose Input 13
32
White/Green
Standard RPM Left Input
33
White/Blue
Standard RPM Right Input
34
Blue
Low Voltage RPM Left Input
35
Green
Low Voltage RPM Right Input
36
Blue
General Purpose TC Input 2+
37
Green
General Purpose TC Input 2-
Table 57–SV-EMS-220 Male D37 Transducer Connector
SV-EMS-220 Female D25
Thermocouple Connector Pin
EMS 25-pin
Thermocouple
Harness Wire Color*
Description
1
Do Not Connect
Do Not Connect
2
Red
CHT6 RED
3
Red
EGT6 RED
4
Red
CHT5 RED
5
Red
EGT5 RED
6
Red
CHT4 RED
7
Red
EGT4 RED
8
Red
CHT3 RED
9
Red
EGT3 RED
10
Red
CHT2 RED
11
Red
EGT2 RED
