` Appendix C: Wiring and Electrical Connections
SkyView System Installation Guide - Revision K 17-11
SV-EMS-220 Female D25
Thermocouple Connector Pin
EMS 25-pin
Thermocouple
Harness Wire Color*
Description
12
Red
CHT1 RED
13
Red
EGT1 RED
14
White
CHT6 WHITE
15
Yellow
EGT6 YELLOW
16
White
CHT5 WHITE
17
Yellow
EGT5 YELLOW
18
White
CHT4 WHITE
19
Yellow
EGT4 YELLOW
20
White
CHT3 WHITE
21
Yellow
EGT3 YELLOW
22
White
CHT2 WHITE
23
Yellow
EGT2 YELLOW
24
White
CHT1 WHITE
25
Yellow
EGT1 YELLOW
Table 58–SV-EMS-220 Female D25 Thermocouple Connector
*Note, this is the 6-cylinder harness.
