Appendix E: Serial Data Output
19-6 SkyView System Installation Guide - Revision K
Parameter
Start
Character
Position
Num
Chars
Range of
values /Units
Example/Notes
CDI Scale
33
2
00 to 50
1/10 * NM
50 (5.0 NM)
XX when not in GPS mode
(there is no scale in NAV or LOC
modes) or CDI invalid
CDI Deflection
Sign
35
1
‘+’, or ‘-’
‘+’ means deflected to right
X if CDI invalid
CDI Deflection
36
2
00 to 99
percent
50 (50 percent deflection)
XX if CDI invalid
Glideslope
Sign
38
1
‘+’, or ‘-’
‘+’ means deflected up
X if glideslope invalid
Glideslope
39
2
00 to 99
percent
50 (50 percent deflection)
XX if glideslope invalid
AP Engaged
41
1
0 to 7
0=Off, 1= roll only, 2=pitch only,
3= roll+pitch, 4=yaw,
5=roll+yaw, 6=pitch+yaw,
7=pitch+roll+yaw
0 if AP not installed
See Note 1
AP Roll Mode
42
1
0 to 3
0=Heading, 1=Track, 2=NAV,
3=GPS Steering,
0 if AP not installed
AP Roll Force
Sign
43
1
‘L’ or ‘R‘
‘L’ mean leftward force exerted
AP Roll Force
44
2
00 to 80
force exerted
by the roll
servo
00 (no force exerted)
80 (max force before slipping)
00 if not engaged or AP not
installed
AP Pitch Force
Sign
46
1
‘U’ or ‘D‘
‘U’ means upward force exerted
AP Pitch Force
47
2
00 to 80
force exerted
by the pitch
servo
00 (no force exerted)
80 (max force before slipping)
00 if not engaged or AP not
installed
AP Yaw Force
Sign
49
1
‘L’ or ‘R‘
‘L’ means leftward force
exerted
